Smart MUTT® (7-Way Round Pin)
Mobile Universal Trailer Tester

  1. Home
  2. Equipment
  3. Smart MUTT® (7-Way Round Pin) Mobile Universal Trailer Tester
#9007A

Smart MUTT® (7-Way Round Pin)
Mobile Universal Trailer Tester

#9007A

Smart MUTT® (7-Way Round Pin)
Mobile Universal Trailer Tester

A portable unit for commercial trailer lighting and ABS.

Find A Distributor
Distributor Information

Innovative Products of America® Incorporated is an OEM (Original Equipment Manufacturer) who only sells through traditional three step distribution. Our products are available through most professional tool distributors, AG/construction equipment dealers, farm supply stores, MRO and industrial supply companies.
To locate a distributor near you, please call 888-786-7899 or email us.

If you do not have access to a local distributor, you may buy directly from our website.

Price $712.50

Description

The Smart MUTT® is a Portable Trailer Light Tester and ABS Tester for the Mobile and Commercial Trailer Repair Technician

Built to facilitate a one-man testing operation, the Smart MUTT® reduces guesswork and inspection time to prevent electrical and ABS failures that lead to expensive road calls and citations. This unit is designed to be used on 7-way round pin trailer connections. The Smart MUTT® provides an easy method to accessing trailer ABS blink codes, and tests ABS fault blink codes via Auxiliary and Brake Circuit activation (i.e. Meritor/Wabco, Bendix® TABS-6 and Haldex systems).



Features and Benefits:

ELECTRICAL TESTING (12 Volt Operation)

  • Power lights: Manually, All-On, Auto Scan, or Remote Control
  • Audible and visual alerts: cross, open, overloaded and short circuit indication
  • Pulsar® mode allows diagnostic repair
  • Advanced trailer wiring diagnostics
  • Amperage readout and range (0-20 amps)
  • Cable testing
  • Ground failure detection: differentiates between wire and chassis ground

ABS TESTING

  • Access ABS blink codes
  • Test ABS fault blink codes via Auxiliary and Brake Circuit activation (i.e. Meritor/Wabco, Bendix® TABS-6 and Haldex systems)

REMOTE CONTROL

  • Remote control included tests all trailer electric circuitry, 200+ ft. range
  • Sync multiple (12) remotes to one unit

Includes:
• 12-Button Remote Control (#MUT-RM12) • 5′ 7-Way Cable (#7900K-1) • 500mA Battery Charger (#CHR0001)

Read Our Full Trailer Testing Blog Here

Connection Type: 7-Way Round Pin
Power Input: 12/24V DC
Battery Requirements: Yuasa #YTX14 or Similar Recommended
Source Output: 20A @ 12/24V DC
Controls: Manual, Remote, Automatic
Material: Powder-Coated Steel
Weight: 15 lbs.
Dimensions: 12" L x 9.5" W x 9" H
Warranty: 3-Year Limited Warranty
CoO: USA

We value your business. Have a question or need technical support? Call 845-679-4500 or email [email protected] When contacting us, please be sure to reference the part number or product series you're interested in.
